Panel Wall Commandoor
Transparency that speaks. The Commandoor brings openness and silence together in one elegant system.
Endless possibilities
The Commandoor is a full glass mobile panel wall. This wall combines the openness and transparency of glass with high sound insulation. The Commandoor is encased in aluminum profiles that guarantee stability. This wall system comes standard with the Multi Electric system. The finishing possibilities are endless.
With attention to detail
Thanks to Multiwal’s in-house production, the possibilities are virtually endless. Not only in terms of the design of your mobile walls, but also in material selection and composition of all movable walls.
Easy to operate
A panel wall gains its rigidity and stability from a strong frame construction. This frame construction consists of a horizontal cassette of aluminum and steel and is equipped with specially developed vertical profiled box sections. Thanks to the sophisticated rail systems and silent rollers, hardly any force is needed to move and park the elements. You can move our walls almost with one finger!
Smart options
Discover the additional possibilities. Each option has been carefully developed to seamlessly blend functionality and design.
Klaar om je ruimte te transformeren?
Laten we samenwerken en ontdekken hoe Multiwal’s innovatieve wandoplossingen jouw omgeving kunnen optimaliseren. Onze experts staan klaar om je te helpen.
Neem contact opProduct expert
Zeg hallo tegen Frits
Vragen over systemen, opties of maatwerk? Ik help je verder.
info@multiwal.nl +31 (0) 786922122Technical details
Dimensions
- Element thickness 92 mm
- Element width 1300 mm
- Maximum element height 4000 mm
Weights
- 40 – 50 kg/m²
Frame construction
- Self-supporting aluminum frame construction
Glass
- Standard VSG
- Optional: ESG, processed and colored glass
Sound insulation
- Laboratory value according to DIN and ISO 10140-2
- Sound insulation from 40 to 50 dB
Vertical profiles
- Conical aluminum profiles spray-painted in RAL color
- With double internal rubber sealing profiles, and equipped with integrated magnetic strip
Vertical connection between elements
- Type U: Approx. 5 mm visible aluminum profiles when wall is closed
Horizontal connection to rail and floor
- Black anodized aluminum pressure beams with double rubbers to compensate for unevenness in the floor
- Able to compensate for structural deviations up to 40 mm
Fire retardant
- F30 minutes and F60 minutes, with and without door and glass
Pass-through doors
- Single or double leaf
- Fixed hinged
Operation
- Semi-automatic
- Optional: Fully automatic
Pressure beam force
- 2 KN/m
- Semi-automatic kN/m adjustable via built-in microprocessor
Rail
- Aluminum
- Standard in RAL 9010
Rollers
- Maximum panel weight 500 kg
Environmental conditions
- Suitable for indoor application
Standard with Commandoor Panel Wall
Standard
Optional
Not possible
| Commandoor U-Line | Commandoor Flush glazed | |
|---|---|---|
| Track profiles in RAL 9010 | ||
| Ceiling overlay profile | ||
| Frame with vertical ‘box’ profiles | ||
| Vertical profiles in RAL color | ||
| Vertical profiles with magnetic closure | ||
| Panel-encompassing vertical profiles | ||
| Concealed vertical profiles | ||
| Semi-automatic operation ‘Multi Electric’ | ||
| Semi-automatic pressure force (adjustable) 2000 kN/m | ||
| VSG safety glass | ||
| ESG safety glass | ||
| No necessary floor guidance | ||
| TÜV tested | ||
| Manual operation via operating crank | ||
| Maximum dB value | 49 | 50 |
| Maximum element height (m) | 4 | 4 |
| Standard maximum element width (m) | 1,3 | 1,3 |
